Recreating the Chameleon: Material Mimics Color Changes Of Living Organisms

ツイート
2018/06/27

Department of Molecular Design and Engineering, Graduate School of Engineering

Miki Sakai, Prof. Takahiro Seki, and Associate Prof. Yukikazu Takeoka

Researchers at Nagoya University develop a composite material that, by adjusting its composition and exposing it to different types of light, can mimic animals’ changes in color

Nagoya, Japan – A range of creatures, including chameleons, octopuses, and frogs, can change color in response to changes in the environment. Some insights into the mechanisms behind this at the anatomical, cellular, and molecular levels have been obtained. However, much work is still required to obtain sufficient understanding of this phenomenon and to translate it into useful artificial applications.

Fig. 1 Color change of pigment obtained by fusing spherical colloidal crystal and diarylethene
Color change in a picture of a morning glory created with the composite color material due to light irradiation and the background color. © 2018 WILEY‐VCH Verlag GmbH & Co. KGaA, Weinheim.

As reported in the journal Small, researchers at Nagoya University's Department of Molecular Design and Engineering developed a material containing dyes and crystals that can change the colors and patterns it displays depending on the background color used within it and its exposure to visible or ultraviolet light.

The team was inspired to develop this material by findings obtained in the skin of certain frogs, in which different layers of cells with different properties combine to enable remarkable color changes.

Each component of this novel material plays a key role in its color properties. For example, the dyes contribute their inherent colors to the material's appearance, which can be adjusted by mixing them to different extents. These dyes also include those that change color upon exposure to light.

Fig. 2 Spherical colloidal crystal
Electron micrographs of spherical colloidal crystals composed of fine silica particles with a particle diameter of 250 nm: (a) image showing one spherical colloidal crystal, (b) surface image of the spherical colloidal crystal, (c) a sectional image of the spherical colloidal crystal, and (d) spherical colloidal crystals maintained between the mesh sizes of 125 μm and 150 µm.© 2018 WILEY‐VCH Verlag GmbH & Co. KGaA, Weinheim

Spherical crystals were also introduced into the system, which rather than influencing the color through their inherent pigmentation affect it through their microscopic structures that can directly interfere with light. Finally, a black pigment and different background colors were employed to alter the colors the other components of the system display.

"We examined the influences of the different components in the system, such as by changing the size of the crystals, switching the background from white to black, or performing exposure to visible or ultraviolet light," corresponding author Yukikazu Takeoka says. "We found these changes resulted in different colors being displayed across the material, resembling the way in which some organisms can change color in response to various factors in their environment."

Fig. 3 Color change accompanying background color change of spherical colloidal crystals
a) A photograph of the spherical colloidal crystals containing 0.20 wt% carbon black (CB). The size of the fine silica particles ranges from 200 to 300 nm, and 11 different sizes were used. b) Picture of a weevil drawn using spherical colloidal crystals prepared using monodispersed silica particles with various particle sizes and CB. The surroundings of the weevils are drawn with spherical colloidal crystals that do not contain CB and change with the color of the background. © 2018 WILEY‐VCH Verlag GmbH & Co. KGaA, Weinheim

"This is an exciting stage in this field of study, as we are increasingly able to adapt the color-changing mechanisms that some animals use to artificial devices," study first author Miki Sakai adds. "If these artificial color-changing materials can equal or surpass the vibrant displays that some animals such as octopuses and frogs make, it could have exciting applications in the development of new display technologies."

*****

The article “Bioinspired Color Materials Combining Structural, Dye, and Background Colors” was published in Small at DOI: 10.1002/smll.201800817.

*****

Authors: Miki Sakai, Takahiro Seki, and Yukikazu Takeoka,

Department of Molecular Design and Engineering, Graduate School of Engineering, Nagoya University

*****
